Space Saving Residential Air Source Heat Pump , Split System Heat Pump

Ask Lasest Price
Brand Name :	Yushen
Model Number :	SLNA-009U(P) SLNA-014UP
Certification :	CCC, ISO, CQC
Price :	negotiable
Payment Terms :	T/T
Supply Ability :	10 sets/day
Delivery Time :	1-2weeks

Add to Cart

Product Details
Company Profile

Space Saving Residential Air Source Heat Pump , Split System Heat Pump

Space Saving Residential Air Source Heat Pump , Split System Heat Pump

Residential Air Source Heat Pump characters

1: Safety operation, no need to be on duty

Compared with gas and coal fired boilers, commercial air-energy heat pumps operate absolutely safety, reducing risks such as, boiler explosions and air leaks, and are intelligently controlled, eliminating the need for dedicated personnel and reducing expenses.

2: High heating efficiency

They can be widely used in hospitals, restaurants, hotels, playgrounds, villas,office building, hotels and other building heating and air conditioning

3. Low operating costs

The energy efficiency ratio of the water source high temperature unit is greater than 4.5, and the operating cost is 1/4-1/3 of the general heating mode, which is obviously lower than that of fuel oil and central heating.

Residential Air Source Heat Pump Parameters

code name.pdf

Model				SLNA(B)-014U(P)
Compressor capacity				5HP
Function				Heating and Cooling
Electricity				220V-1N-50Hz
Working conditions			℃	-25~～+45
Data	Heata	Nominal capacity	KW	9.2
		Input power	KW	3.96
		COP	/	2.3
	Heating IPLV(H)			2.6
	Coolb	Nominal capacity	KW	11.0
		Input power	KW	4.31
		COP	/	2.55
	Cooling IPLV(C)			2.75
	A7W35c		KW/COP	14.0/4.1
	A2W35		KW/COP	11.2/3.60
	A-7W35		KW/COP	9.5/3.0
	A-15W55		KW/COP	8.4 /1.94
	A-20W45		KW/COP	7.7/2.00
Max. running currency			A	30
Compressor quantity			set	1
Refrigerant/charging quantity kg			/	R22/4.50
Air blow type			/	Side
Water pipe diameter			inch	G1.2〞
Rating flow			m³/h	2.5
Water side pressure loss			kPa	≤35
Noise level			dB(A)	61
Overall dimensions(L×W×H)			mm	1120×440×1360
Weight			kg	130

a: Nominal heating conditions: ambient dry bulb temperature-12℃, wet bulb temperature-14℃, outlet water temperature 41℃, water flow 0.172 * nominal heating capacity

b:Nominal refrigeration conditions: ambient dry bulb temperature 35℃, outlet water temperature 7℃, water flow 0.172 * nominal cooling capacity

c:A7W35 working condition: inlet air temperature 7℃, outlet water temperature 35℃
